Collection: SA200

Temperature Controllers

  • Measurement accuracy: ±0.3% of displayed value
  • Sampling time: 0.5sec./0.25sec.
  • LCD display
  • 48×24mm size (horizontal by vertical)
  • Plug-in construction





48(W)×24(H)mm sized compact temperature controller

-Compact size controller that can be mounted on a small panel space
-Large easy-to-read PV display on a compact front panel



Control state discriminating type self-tuning

-PID parameters are automatically tuned when control is determined to be disturbed.
-Autotuning function is also available.



Communication function (RS-485) is available (Optional)

-Up to 31 controllers can be multidrop connected over the RS-485 communication line.
-Communication protocol can be selected from RKC standard or MODBUS protocol.



Analog Retransmission Output function is available (Optional)

The output 1 can be configured as an analog  retransmission output.
With this function, the measured value can be retransmitted as an analog current signal  (4-20mA /0-20mA).



Two types of colors; black base or white base

Two types of colors are offered to match the machine.



 Model and Suffix Code



For inquiries about products with different model names, please contact our customer service.
